Toyota 4RUNNER 2012 - Page 534

561
4-3. Do-it-yourself maintenance
4
Maintenance and care
4RUNNER_U
*: Replace the fuse with one of the same ampere rating as the origi-
nal
39 ALT
140 A*
HTR, 400W INV, A/C COMP,
TOWING TAIL, SUB BATT,
MIR HTR, DEF, DEICER,
STOP, PTC HTR NO.1, PTC
HTR NO.2, PTC HTR NO.3,
S/HTR FR, ACC, P/OUTLET,
IG1, ECU-IG NO.1, ECU-IG
NO.2, WIP, WASHER, KDSS,
4WD, BKUP LP, TOWING
BKUP, DOOR P, DOOR RL,
DOOR RR, DOOR D, P/SEAT
FL, P/SEAT FR, DOOR, A/C,
OBD, DOOR BACK, S/ROOF,
PANEL, TAIL, FOG FR, D/L
NO.2 fuses
40 SPARE
10 A
⎯
41 SPARE
15 A
⎯
42 SPARE
20 A
⎯
43 P/I-B
80 A
IG2, EFI, A/F, HORN fuses
44 SECURITY
10 A
Multiport fuel injection system/
sequential multiport fuel injec-
tion system
45 SMART
7.5 A
Smart key system
46 STRG LOCK
20 A
Steering lock system
47 TOWING BRK
30 A
Trailer brake controller
Fuse Ampere Circuit
