6-3. Do-it-yourself maintenance

AVALON (U)_(01999-07001)

■

Front

Bulb locations

Headlight low beam (halogen bulb)

Headlight high beam and daytime running light (vehicles with halo-

gen bulbs for low beams)

Headlight high beam (vehicles with discharge bulbs for low beams)

Front turn signal/parking light

1

2

3
