Toyota CQ-TS6670LC User Manual

7 REPLACEMENT PARTS
LIST
Notes :
1. Be sure to make your orders of replacement parts
according to this list.
2. Important safety notice: Components, identified by
mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3. Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4. The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
Ref.
No.
Part No. Part Name & Description Remarks
[E9512B] CD Servo Block
IC´s AND TRANSISTORs
IC101 MNG7945ECUC IC
IC301 MNBC77CWPUC IC
IC302 C3EBDG000058 IC
IC901 AN41015A-VF IC
IC904 C0CBABF00024 IC
IC905 C0JBAE000333 IC
Q1 B3HB00000022 Transistor
Q3 B3HB00000022 Transistor
Q6 B3HB00000022 Transistor
Q101 B1ADBD000005 Transistor
Q901 B1GBCFCJ0005 Transistor
DIODEs
D301 MA152WKTX Diode
D801 B3EB00000014 Diode
D803 B3EB00000014 Diode
D806 B3EB00000014 Diode
CAPACITORs
C101 F1H0J1050010 Ceramic, 1µF 6.3WV
C102 F1H1H471A792 Ceramic, 470PF 50WV
C103 YECUZ1C104KX Ceramic, 0.1µF 16WV
C104 F3H0J1070005 Tantalum, 100µF 6.3WV
C106 F1H1H820A231 Ceramic, 82PF 50WV
C107 F1H1H820A231 Ceramic, 82PF 50WV
C108 F1H1H820A231 Ceramic, 82PF 50WV
C109 F1H1H820A231 Ceramic, 82PF 50WV
C111 F1H0J1050010 Ceramic, 1µF 6.3WV
C112 F1H1H471A792 Ceramic, 470PF 50WV
C115 YECUZ1C104KX Ceramic, 0.1µF 16WV
C116 YECUZ1C104KX Ceramic, 0.1µF 16WV
C117 F1H0J1050010 Ceramic, 1µF 6.3WV
C118 F1J0J106A014 Ceramic, 10µF 6.3WV
C119 YECUZ1C333KX Ceramic, 0.033µF 16WV
C121 YECUZ1C104KX Ceramic, 0.1µF 16WV
C122 F1J0J106A014 Ceramic, 10µF 6.3WV
C124 YECUZ1C104KX Ceramic, 0.1µF 16WV
C125 YECUZ1C104KX Ceramic, 0.1µF 16WV
C126 F1H1H821A190 Ceramic, 820PF 50WV
C127 F1J0J106A014 Ceramic, 10µF 6.3WV
C128 YECUZ1E223KX Ceramic, 0.022µF 25WV
C129 YECUZ1C104KX Ceramic, 0.1µF 16WV
Ref.
No.
Part No. Part Name & Description Remarks
C130 F1H1H102A831 Ceramic, 1000PF 50WV
C131 YECUZ1C104KX Ceramic, 0.1µF 16WV
C132 F1H0J1050010 Ceramic, 1µF 6.3WV
C136 F1H0J1050010 Ceramic, 1µF 6.3WV
C139 YECUZ1C104KX Ceramic, 0.1µF 16WV
C140 F1H1H103A221 Ceramic, 0.01µF 50WV
C143 F1H1H1010005 Ceramic, 100PF 50WV
C151 F1H0J1050010 Ceramic, 1µF 6.3WV
C160 F1H1H820A231 Ceramic, 82PF 50WV
C161 F1H1H820A231 Ceramic, 82PF 50WV
C162 F1H1H820A231 Ceramic, 82PF 50WV
C163 F1H1H820A231 Ceramic, 82PF 50WV
C301 YECUZ1C104KX Ceramic, 0.1µF 16WV
C302 F1H1H103A221 Ceramic, 0.01µF 50WV
C304 F1H0J1050010 Ceramic, 1µF 6.3WV
C502 F1H1H820A231 Ceramic, 82PF 50WV
C503 F1H1H820A231 Ceramic, 82PF 50WV
C504 F1H1H820A231 Ceramic, 82PF 50WV
C506 F2A1A101A450 Electrolytic, 100µF 10WV
C507 F1H0J1050010 Ceramic, 1µF 6.3WV
C508 F1H0J1050010 Ceramic, 1µF 6.3WV
C901 YECUZ1C104KX Ceramic, 0.1µF 16WV
C902 F1H1H1010005 Ceramic, 100PF 50WV
C903 F1H1H1010005 Ceramic, 100PF 50WV
C909 F2A1A101A450 Electrolytic, 100µF 10WV
C911 F2A1A101A450 Electrolytic, 100µF 10WV
C912 YECUZ1C104KX Ceramic, 0.1µF 16WV
C913 YECUZ1C104KX Ceramic, 0.1µF 16WV
C914 YECUZ1C104KX Ceramic, 0.1µF 16WV
C919 YECUZ1C104KX Ceramic, 0.1µF 16WV
C922 F2A1A101A450 Electrolytic, 100µF 10WV
C923 F1H0J1050010 Ceramic, 1µF 6.3WV
C972 F1J0J106A014 Ceramic, 10µF 6.3WV
C973 F1J0J106A014 Ceramic, 10µF 6.3WV
RESISTORs
FL103 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/16W
FL901 ERJ8GEYJ2R2V Chip, 2.2Ω
ΩΩ
Ω 1/8W
FL902 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/10W
FL903 ERJ8GEYJ2R2V Chip, 2.2Ω
ΩΩ
Ω 1/8W
R101 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω 1/16W
R102 ERJ3GEYJ333V Chip, 33kΩ
ΩΩ
Ω 1/16W
R104 ERJ6GEYJ1R0V Chip, 1Ω
ΩΩ
Ω 1/10W
R106 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω 1/16W
R107 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/10W
R108 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω 1/16W
R109 ERJ3GEYJ333V Chip, 33kΩ
ΩΩ
Ω 1/16W
R111 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω 1/16W
R112 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω 1/16W
R115 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/16W
R124 ERJ3GEYJ823V Chip, 82kΩ
ΩΩ
Ω 1/16W
R125 ERJ3GEYJ561V Chip, 560Ω
ΩΩ
Ω 1/16W
R126 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/16W
R127 ERJ6GEYJ220 Chip, 22Ω
ΩΩ
Ω 1/10W
R130 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/16W
R131 ERJ3GEYJ332V Chip, 3.3kΩ
ΩΩ
Ω 1/16W
R132 ERJ3GEYJ121V Chip, 120Ω
ΩΩ
Ω 1/16W
R133 ERJ3GEYJ121V Chip, 120Ω
ΩΩ
Ω 1/16W
R134 ERJ3GEYJ121V Chip, 120Ω
ΩΩ
Ω 1/16W
R135 ERJ3GEYJ104V Chip, 100kΩ
ΩΩ
Ω 1/16W
R141 ERJ3GEYJ105V Chip, 1MΩ
ΩΩ
Ω 1/16W
R151 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/16W
R152 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/16W
R301 ERJ3GEYJ563V Chip, 56kΩ
ΩΩ
Ω 1/16W
R305 ERJ3GEYJ332V Chip, 3.3kΩ
ΩΩ
Ω 1/16W
R313 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/16W
R314 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω 1/16W
R503 ERJ3GEYJ473V Chip, 47kΩ
ΩΩ
Ω 1/16W
R504 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/16W
R505 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/16W
R507 ERJ3GEYJ473V Chip, 47kΩ
ΩΩ
Ω 1/16W
R508 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/16W
6
