322
4-3. Do-it-yourself maintenance
HILUX_AE (OM0K101E)
Stop/tail lights, rear turn signal lights and back-up lights
Remove the securing bolts and
remove the unit.
Turn the bulb base counterclock-
wise.
Stop/tail light
Rear turn signal light
Back-up light
Remove the light bulb.
Stop/tail light
Rear turn signal light
Back-up light
STEP
1
STEP
2
STEP
3
Not for Reproduction
