108
2. Instrument cluster
RAV4_OM_OM42873E_(EE)
Gauges and meters
The units used on the speedometer may differ depending on the target
region.
Tachometer
Displays the engine speed in revolutions per minute
Speedometer
Displays the vehicle speed
Fuel gauge
Displays the quantity of fuel remaining in the tank
Shift position and shift range (vehicles with an automatic transmis-
sion or a Multidrive)
Displays the selected shift position or selected shift range
(P. 246, 253, 262)
Multi-information display
Presents the driver with a variety of driving-related data (P. 109)
To prevent damage to the engine and its components
Do not let the indicator needle of the tachometer enter the red zone, which
indicates the maximum engine speed.
1
2
3
4
5
To Next Page
