TP active fun TP509 - Step 4: Frame Bracing; Step 5: Angled Support Installation

10
TP509 Small to Tall Swing Frame
4
FC0129 x2
M6 x50mm
FA5155 x4
M6
FA9764 x4
M6
FA9023 x4
5
PR9662 x4
M6 x 32mm
FA7250 x4
M6
FA9764 x4
M6
FA9023 x4
45°
45°
45°
45°
45°
Low Height Frame Assembly
Full Height Frame Assembly
Low Height Frame Assembly
