TP active fun TP509 - Step 6 & 7: Frame Reinforcement

11
TP509 Small to Tall Swing Frame
6
FC9908
x2
M8 x 83mm FA8057
x2
30mm
FA2825 x2
3
FC0125 x4
M6 x 32mm
FA7250 x4
M6
FA9764 x4
M6
FA9023 x4
7
Full Height Frame Assembly
21
