II. Specifications
Electrical Specifications
Model TL-ANT5823B
Frequency Rang-MHz 5150-5850
Gain-dBi 23
VSWR ≤1.5
Horizontal Beamwidth-° 12
Vertical Beamwidth-° 12
Polarization Vertical or Horizontal
F/B Ratio-dB ＞28
Impedance-Ω 50
Maximum Input Power-W 100
Connector N Female
Mechanical Specifications
Antenna Dimension-mm 320×320×20
Weight-Kg 1,8
Mounting Mast Diameter-mm Ø30～Ø50
Radome Material ABS
Rated Wind Velocity-Km/h 241
