General| Wi-Fi | Yes |
|---|---|
| Modulation | 16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM |
| Wi-Fi band | Single-band (2.4 GHz) |
| Frequency range | 2.4 - 2.4835 GHz |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Maximum data transfer rate | 300 Mbit/s |
| WLAN data transfer rates supported | 11, 54, 300 Mbit/s |
| Interface | WLAN |
| USB version | 2.0 |
| USB ports quantity | 1 |
| Connectivity technology | Wireless |
| Internal | No |
| Antenna type | 2x Omni |
| Certification | CE, FCC, RoHS |
| Component for | - |
| Product color | White |
| Receiver sensitivity | 270M: -68dBm@10% PER 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER |
| Antenna direction type | Omni-directional |
| Antenna gain level (max) | 3 dBi |
| Cable length | 1.5 m |
| Dimensions (WxDxH) | 90 x 68 x 16.8 mm |
| Operating temperature (T-T) | 32 - 104 °F |
| Compliance industry standards | IEEE 802.11b/g/n |
| Dimensions (W x D x H) (imperial) | 3.5 x 2.7 x 0.7 \ |
| Compatible operating systems | Windows 2000 / XP / Vista / 7 |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1, Windows XP |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
| Operating relative humidity (H-H) | 10 - 90 % |
| Cables included | USB |
| Package depth | 150 mm |
| Package width | 200 mm |
| Package height | 39 mm |
| Package weight | 210 g |
| Harmonized System (HS) code | 85176990 |
Weight and Dimensions| Depth | 68 mm |
|---|---|
| Width | 90 mm |
| Height | 16.8 mm |
