Connect the INTERNET port of your Router to the PoE port on the
Passive PoE injector with an Ethernet Cable.
Connect your computer to the LAN port of your Passive PoE
injector with an Ethernet Cable.
Plug the provided power adapter into the DC jack on the Passive
PoE injector, and the other end to a standard electrical wall socket.
Press the ON/OFF button to power on the Router.
Note
1. The passive PoE injector supports a cable length up to 30
meters due to the environment.
2. If you need a longer data transmission distance (not
exceeding 100 meters), TP-LINK’s 48V PoE adapters
such as TL-POE200, TL-POE150S and TL-POE10R are
recommended.
Product information can be found on our ofcial website http://www.tp-
link.com.
Appendix 2: With PoE Setup
SOCKET
Passive PoE Injector
Notebook
WISP Signal
TL-WR843ND
To Next Page
