TP 233 Series - Page 33

31
*Front & Rear Chain Guards (Standard with 5’ Stainless Steel Kutter)
Ref.
No.
Part Name Part Number
Rotary Mower Size 4 Ft.
40 HP
5 Ft.
40 HP
Stainless
5 Ft.
40 HP
6 Ft.
40 HP
1 Tire & Rim /w Hub 403001 403001 403001 403001
2 Wheel Fork Assembly 403019 403019 403019 403019
3 Wheel Hub Assembly 191100 191100 191100 191100
4 A-Frame Assembly 401024 401024 401024 401009
5 A-Frame Height Adjust. 310099 310099 310099 310099
6 Gear Box Slick 184000 184005 - 184005
7 Lift Arm Brace 360685 310060 310060 310060
8 PTO Shaft w/Shear Pin 147029 147234 - 147242
9 Lift Arm Assembly 403661 403663 403663 403663
10 Cat. 1 Lift Pins (Pkg. 2) 500001 500001 500001 500001
11 Swivel Link Set (Pkg. 2) 502010 502010 502010 502010
12 Stump Jumper 403031 403031 403031 403034
13 Mower Blade Set (Pkg.2) 501118 501124 501124 501130
14 Blade Bolt Set (Pkg.2) 501001 501001 501001 501001
15 Wheel Washer Kit 501013 501013 501013 501013
16 Pivot Shield Kit 501029 501029 501029 501029
17 Castle Nut & Cotter Pin Pkg. 501110 501110 501110 501110
18 Rear Chain Guard (Optional) 403971 403973 *403973 403975
19 Front Chain Guard (Optional) 403970 403972 *403972 403974
20 Pivot Bar 401031 401031 401031 401031
21 Spacer & Bolt Kit 501095 501095 501095 501095
22 Shear Bolt Kit (Pkg. 5) 500101 500101 - 500101
23 Axle Bolt w/Nut 501280 501280 501280 501280
24 Brace Arm Spacer Kit 501500 501500 501500 501500
6 Ft.
60 HP
403001
403019
191100
401009
310099
-
310060
-
403663
500001
502010
403036
501130
501001
501013
501029
501110
403975
403974
401031
501095
-
501280
501500
6 Gear Box Splined - 184010 184010 184010 184065
8 PTO Shaft w/Slip Clutch - 147134 147134 147342 147142
22 Slip Clutch - - Pg. 34 - Pg. 34
