TP 233 Series - PTO Shafts Cover Removal; Bondioli- (BYPY); Eurocardan Series 4; La Magdalena

33
SLIP CLUTCH PTO SHAFT
Ref.
No.
Part Name
147134
1 Cross Kit 170020
2 Roll Pin 500131
3 Female Tube End Yoke 151070
4 Inner Tube 151092
5 Slip Clutch Assembly Page 34
6 Male Tube End Yoke 151065
7 Outer Tube 151093
8 Tractor End Yoke 151055
9 Quick Disconnect Pin 170110
10 Safety Shield BYPY 124315
10 Safety Shield Eurocardan 124316
