TP 233 Series - Page 41

Ref.
No.
Part Name Gearbox
184000
1 Snap Ring 106138
2 Input Seal (NAK 35 x 54 x 10) 156010
3 Front Cap 129015
4 Front Cap Gasket 124130
5 Snap Ring 131031
6 Snap Ring 131030
7 Bearing (Hoover 208) 155005
8 Input Gear 185007
9 Input Shaft 186010
10 Bearing (NSK 6207) 155010
11 Housing 129010
12 Output Shaft 185005
13 Spacer -
14 Output Seal (NAK 40 x 54 x 7) 156005
15 Bottom Cap Gasket 124131
16 Bottom Cap 129005
17 1’ Castle Nut /w Washer & Cotter Pin 501110
18 1/2” Pipe Plug 131035
19 1/8” Pipe Plug 131040
20 3/8” x 1” Bolt & Lock washer -
Gearbox
184005
106138
156010
129015
124130
131031
131030
155005
185010
186010
155010
129010
185006
131045
156005
124131
129005
501110
131035
131040
-
Gearbox
184010
106138
156010
129015
124130
131031
131030
155005
185010
186005
155010
129010
185006
131045
156005
124131
129005
501110
131035
131040
-
39
