TP TP305 - Step 8: Upper Floor Supports; Step 9: Ladder Construction

10
Adventure Playhouse
4.5 x 50mm
x3
MW2573
x2
(1300mm)
MW2009
x1
(915mm)
4.5 x 50mm
x2
No10 x 38mm
x12
MW1501
x3
(414mm)
MW0172 x2
(997mm)
MW2573
MW2573
MW2009
250mm
250mm
MW0172
MW1501
MW1501
MW1501
MW0172
90mm
No 10 x 38mm
4.5 x 50mm
8
9
MW2009
