TP TP305 - Installation and Anchoring; Anchoring Steps; Sandpit Liner Installation

15
Adventure Playhouse
4.5 x 50mm
x2
PM2001
x2
x2
Dig holes:
300mm x
300mm x
300mm deep.
Mark leg/hole position.
1 2 3
Ensure the stakes are
positioned into the
setting Post-Mix concrete.
Warning: Never set
the legs/base of the
playset in concrete.
Not
Supplied.
Fill holes with Post-Mix concrete.Fix stakes to legs with
fixings supplied.
5 64
x2
300mm
300mm
300mm
15
1 2 3 4 5 6 1
FB9985 Sandpit Liner
x1
Sand Not
supplied
16
