TP TP305 - Step 2: Lower Structure Assembly; Step 3: Mid-Level Structure

7
Adventure Playhouse
MW2566
x2
(1069mm)
5 x
100mm
5 x 100mm
5 x 100mm
MW2566
MW2566
4.5 x 50mm
x4
MW2565
x2
(1159mm)
5 x 100mm
MW2565
MW2565
4.5 x 50mm
4.5 x 50mm
4.5 x 50mm
4.5 x 50mm
5 x 100mm
x4
2
3
