TP TP656 - Page 14

8
9
TP656 – TP Treehouse Wooden Play Tower
14
     
.
90mm
250mm
250mm
C
D
D
D
C
= mm
B
B FA4541 3.5x60mm
wood screw x3
C
C FA4523 3.5x50mm
wood screw x2
D
D FA4516 3.5x35mm
wood screw x12
8
8 MW3016 x1 919mm
9
9 MW3015 x2 1185mm
16
16 MW3003 x3 414mm
17
17 MW3002 x2 995mm
D
D
D
= mm
