Func. Name Descriptions
Range of
Setting
Unit
Factory
Setting
Note
F4.36
Current Limit
(I-limit)
Current over F4.36
the rated
current of drive during operation,
the drive may adjust PWM ouput
and limit output current.
30%~200%
of drive
rated current
1% 180
*Note 9
F4.37
Gain of I-limit
The gain of the current limitation
response(P).
0.00~1.00 0.01 0.10
*Note 9
F4.38
Integration Time
of I-limit
Lower integration time I setting
value will result the current
limitation response more fast but
lower setting value would cause
the effect of oscillating current.
0~10.0 0.1 0.6
*Note 9
F4.39
Selection of
Current
Limitation
0:Disable
1:Enable
0,1 ─ 0
*Note 9
The color as means functions can be set during the operation.
32
