6-2 The Setting of Communication Parameter
●F6.55 Communication Address：00~254（00—Disable）
●F6.56 Baud Rate：
0: 4800bps
1: 9600bps
2: 19200bps
●F6.57 Communication Format：
0: 8,N,2 for RTU
1: 8,E,1 for RTU
2: 8,O,1 for RTU
●F6.58 Communication Overtime (Cot)：
0.0: No overtime detection
0.1~100.0sec: The setting of overtime detection
●F6.59 Communication Overtime Disposal：
0: Warning (Cot): Continue operation
1: Warning (Cot): Ramp to stop
2: Warning (Cot): Coast to stop
●F6.60 Multi-Function Input Selection：
0: Multi-function inputs from multi-function terminals
1: Multi-function inputs from communication control
6-3 Communication Protocol
Serial data transmission is an asynchronous serial data transmission: 1 frame =
11 bits (3 types of format shown in below figures)
 8,N,2: 1 start bit，8 data bits，2 stop bits
START BIT 0 BIT 1 BIT 2 BIT 3 BIT 4 BIT 5 BIT 6 BIT 7 STOP STOP
 8,E,1: 1 start bit，8 data bits，1 even parity bit，1 stop bit
START BIT 0 BIT 1 BIT 2 BIT 3 BIT 4 BIT 5 BIT 6 BIT 7
EVEN
PARITY
STOP
 8,O,1: 1 start bit，8 data bits，1 odd parity bit，1 stop bit
START BIT 0 BIT 1 BIT 2 BIT 3 BIT 4 BIT 5 BIT 6 BIT 7
ODD
PARITY
STOP
