TPI Phenomenal Aire R series User Manual

RIOM 3�0
Ref:
Descripon
Part #
O-Ring, Lid
R6-OO3
R6-OO7
Fuse-holder
R6-O10
Duct Collar / Gasket
R6-OO4
R6-O13
R6-OO1
Lid
Tab, Lid - Thru-bolt
Tab, Body - Thru-bolt
R6-OO8
Strain Relief Nut
Mounng Tab (2)
R6-OO9
“Power-on” LED
R6-OO2
Body
R6-OO5
CPG* Legs (2)
* Cold Plasma Generator
R6-O12
Cap, Alt. Power Feed-thru
R6-O11
Fuse, 250 wa AC, 1Amp
PCB Assy:
Power-in Terminal Block
R6-O14
Bolt & Nut, Security
Power Cord Strain Relief Fing
R6-OO6
Power Cord
Warning
1. Do not touch electrodes or needles while operating. You may
experience a static shock.
2. Do not use an extension cord to plug in the product.
3. Always disconnect power before installing or servicing.
4. Always disconnect power before attempting to replace the fuse.
5. The product should be installed in an area with access for
maintenance & inspection.
6. This product is suitable for installing into a duct of metallic or
fiber duct board.
7. If cleaning CPG legs, take care to not damage needlepoints.
Components
Specications
3.75
ʺ
Ø
5.5
ʺ
Ø
3.5
ʺ
2.7
ʺ
6.5
ʺ
C-6.0
C-6.0
10.25
ʺ
Ionization
Needlepoints
1
1
1
1
1
Ionization
Needlepoints
1
1
to 24v AC
 ETL Listed
 Air Flow Capacity: 0 to 6,000 CFM
 Ion Output:
140 million ions/cm3
 Voltage: 16 - 35 VAC
(24 VAC power supply req'd.)
 Pressure Drop: < 0.05” WC
 Power Consumption: 12 VA
 Ion Emitter Leg Length: 6”
 Frequency: 50 Hz -60 Hz
 Electrode: Carbon Resin
 Temperature Range: -20 F to 140 F
 Ionization Generation:
Needlepoint, Bi-Polar
