LED lamp TRACER “S” with PIR sensor 350 mAh
Instruction manual
EN
Please read and retain for future reference the following carefully to ensure the
satisfactory and safe operation of the light.
Note:
• This appliance is intended for domestic use only.
• Before the rst use, remove all packaging elements.
• Unwind and straighten the USB cable before use.
• Make sure that the USB cable has no visible damage.
• Make sure that the USB cable is not stretched over an open ame or other heat
source that may damage the cable insulation.
• The USB cable must be positioned so as not to present a risk of tripping or
entanglement
• This product is not a toy. Make sure children are supervised and do not play with
the product
• This device is not intended for use by persons (including young children)
with reduced physical, sensory or mental abilities or without experience and
knowledge, unless they are supervised or instructed in the use of the device by
a person responsible for their safety.
• Do not expose the device to moisture.
Package includes:
lamp
USB cable
instruction manual
Product description:
Use direction
You can use this incredibly functional LED lamp in any place where light is needed
without connecting it to the electricity network, e.g. Perfect for lighting the corridor,
basement, interior of the wardrobe, stairs, shelves in the car, etc. The LED lamp
has a motion sensor that detects movement within 120° at a distance of up to
3 m. The lamp has a sensor thanks to which it reacts only in dark environment.
Thanks to this function, it will not turn on unnecessarily when the surroundings are
illuminated despite the detected movement.
The lamp has 2 possible settings: dim or bright light.
Lamp has a built-in battery. When the lamp is discharged, charge it using the
attached in the packaging USB cable.
Operating the lamp:
1. Remove the product from packaging. Before rst use, we advise you to connect
the lamp for charging. While lamp is connected to a power source for charging
the red light indicator will light up. Once the lamp is fully charged the indicator
light colour will turn green should turn red. After charging, press the on / o
lamp button.
2. The lamp has 4 possible colour temperatures: to turn them on slowly press the
on / o button. With each button press the light will go to the next temperature.
Possible light colorus: cold, warm, very warm, neutral.
3. The lamp has dimming function for each of the light colours: to dim or brighten
the light, hold down the on / o button for a while on the selected colour.
4. Leaving the button pressed only once (and possibly a second time to dim the
light intensity) on the selected colour - the lamp will remain in the standby mode
and will turn on after detecting movement in a dark environment. The lamp will
turn on for approximately 13 seconds when motion is detected and then turn
o automatically. In this mode, on a fully charged battery, the lamp will turn on
approximately 1100 times.
5. The lamp can also be set in the continuous operation mode (on a fully charged
battery it will be about 1.5 hours - depending on the selected colour of light and
light intensity). To set this mode, press the on / o button 2 times (quickly) on the
selected light colour. To turn this mode o, press the button again 2 times. To
switch the standby mode, press the button only once leaving the lamp on at the
selected colour.
NOTE: The sensitivity of the sensor decreases in very cold or very hot
environments.
WHEN THE BETTERY IS FULLY CHARHED PLEASE DISCONNECT THER
POWER CABLE. THE LAMP IS NOT ADAPTED TO WORK WITH THE POWER
CORD CONTINUOUSLY CONNECTED.
Installation:
1. Remove the protective strip from the adhesive magnetic tape and then place
it on the selected surface, place that you want to illuminate. The place should
be a at, smooth (non-porous) and dry surface, not susceptible to moisture (we
advise not to install the lamp in the bathroom or other places that are constantly
exposed to moisture) NOTE: After sticking the adhesive magnetic tape on, it will
be dicult to remove. Once been removed it will not be reusable.
2. Place the lamp with the magnetic panel facing the magnetic tape.
3. The lamp can also be placed on other metal surface thanks to the magnetic
panel on its back.
NOTE:
1. The 3 -meters motion detection distance was tested in dark environment. If
environment it too bright or there are any objects in front of the PIR sensor it will
aect the motion detection.
2. This product has its best detection when installed at the height of 1 - 1.5m.
Safe use instruction
1. Do not cover the lamp with any objects that may have an inuence for PIR
sensor
2. Do not pull the power cable
3. Be careful with hot surfaces
4. Do not stare at the light source
5. Do not touch with wet hands
6. Indoor use only
7. Protect against rain and moisture
8. Do not throw it
9. The product is not a toy
The light source of this luminaire is not replaceable; when the light source is worn
out, the entire lighting tting must be replaced
Parameters:
Supply voltage: 5V DC 0.5A
Power: 0.3W
Non-replaceable light source: 3528 SMD x 21 pcs. diodes
Useful luminous ux: 30 lm
Color temperature: 3000-6500k
IP class: IP20
Battery: 350mAh / Li-Po 3.7V
Net weight: 72g
Dimensions: 15x2.8x1cm
Charging time: approx. 2h
Product disposal:
1. Packaging components in the form of paper, cardboard and similar materials should
be transferred to waste paper or thrown into waste containers intended for paper
2. Plastic elements such as polystyrene, lms, granular llers and similar should be
thrown into containers intended for plastics
PIR sensor
Light panel
Mounting eye (additional
mounting option)
Self-adhesive magnetic
tape
Magnetic panel
Micro USB input (for
battery charging)
ON/ OFF button
