distance from the microphone and helps to maintain reasonable
recording levels.
• Experimentation should be made with the angle from which the
microphone is addressed, as di󰀨erent results can be achieved when
the vocalist is 'o󰀨-axis'to the microphone.
Install stand on table
1. Screw the TABLE CLAMP
on the edge of a table.
2. Insert the ADJUSTABLE
ARM into the hole.
3. Fasten the screw.
4. Fix Shock mount with
Microphoen stand.
Specications
• Microphone-core: Dia.16mm Condenser
• Polar Pattern: Cardioid
• Frequency Response: 30Hz-16kHz
• Sensitivity: -38dB +/- 3dB (0dB=1V/Pa at 1 kHz)
• Equivalent Noise Level: 16dBA Max.
• Maximum SPL: 120dB
• S/N Ratio: 70dB
• Electrical Current: 3mA
• Voltage: 1.5V
• Body Weight: 7.2oz/205g
• Color: Black
• Material: Metal
