Important Cut-out Information
Cabinet or hood cutouts should be at least
1
/
8
” larger than the following outside dimensions
Models Available (by Width)
Pic
CFM
28
3
/
8
”
34
3
/
8
”
40
3
/
8
”
46
3
/
8
”
52
3
/
8
”
58
3
/
8
”
Sones
Control
Blower
A
390
VSL4303RC
VSL4363RC
VSL4423RC
-
-
-
4
3-Speed
Internal Motor
B
390
VSL4304RC
VSL4364RC
VSL4424RC
-
-
-
7
3-Speed
Internal Motor
C
600
VSL4306RC
VSL4366RC
VSL4426RC
VSL4486RC
-
-
7.5
3-Speed
Internal Motor
D
1200
-
-
VSL44212RC
VSL44812RC
VSL45412RC
VSL46012RC
8.5
(2), 3-Speed
Two Internal
Motors
Notes:
1. Center of electrical access is 7” from front & 2
1
/
2
” from side of liner.
Connection access is behind filters.
2. Vent is 8” (models 430 & 436) or 10” (442, 448, 454, & 460).
Damper not included.
3. Length & width cutouts should be
1
/
8
” larger than above
dimensions.
1. Center of electrical access is 7” from front & 2
1
/
2
” from side of
liner. Connection access is behind filters.
2. Vent is 3
1
/
4
” x 10” centered left to right. Damper is included.
3. Length & width cutouts should be
1
/
8
” larger than above
dimensions.
Notes:
1. Center of electrical access is 7” from front & 2
1
/
2
” from side of liner.
Connection access is behind filters.
2. Damper not included.
3. Length & width cutouts should be
1
/
8
” larger than above
dimensions.
1. Center of electrical access is 7” from front & 2
1
/
2
” from side of
liner. Connection access is behind filters.
2. Damper not included.
3. Length & width cutouts should be
1
/
8
” larger than above
dimensions.
Notes:
C
B
A
Notes:
D
