7
Location of Parts
1. Choke
2. Rear Wheel
3. Footrest
4. Front Wheel
5. Remote Engine Stop Switch
1. Spark Arrester
2. Seat
3. Rear Brake Pedal
4. Footrest
5. Front Brake Lever
1
234
5
