JOY RIDER PARTS L ST
ITEM PART# DESCRIPTION QTY. ITEM PART# DESCRIPTION QTY.
1. 11871 TRIKE REFLECTOR KIT 1 49. 18227 BRAKE CABLE JOY RIDER 1
2. 12069 BASKET HOLD DOWN 7 50. 12269 CABLE TIE, BLACK 2
3. 19171 SCREW 10-32x3/8 RHMS 8 51. 12201 SCREW 1/4x3/8 HW HEAD TYPE B 1
4. 12170 NUT 10-32 HEX KEPS 12 52. 18220 AXLE HOLDER REAR JOY RIDER 2
5. 12208 SCREW 5/16-18x3/4 HHCS 3 53. 12240 WASHER SPACER 1x41/64x.062 1
6. 18306 BRACE REAR FENDER JR/BP 4 54. 11070 PIN COTTER 3/32x1 1
7. 11748 FENDER 24"MWT TRIKE REAR (OPT 2 55. 18709 WHEEL 24x1.75 MAG L. REAR 1
8. 18204 FRAME JOYRIDER 1 56. 18207 WHEEL 24x1.75x36x.080 L. REAR 1
9. 12215 SCREW 5/16-18x3/4 CARRIAGE 4 57. 18203 AXLE JOY RIDER REAR 1
10. 12244 PIN ROLL 3/16x1-1/4 1 58. 18196 PLUG TUBE 1-1/2" ID 2
11. 18860 PIN GROOVE 3/16x1-1/4 ALLOY 1 59. 11801 GRIP 7/8 BLACK 2
12. 12246 KEY, SQUARE 3/16x5/8 2 60. 11654 BRAKE CALIPER LCK. LVR. ALLY. 1
13. 18199 SPROCKET 13T 1 61. 16937 SCREW 3/8-16x3/4 F/H WHIZ-LOC 2
14. 11066 SET SCREW 5/16-18x5/16 HEX 2 62. 18287 CRANK JR/DJ 1
15. 11643 BEARING SP 2 63i 18909 SPROCKET 21T* 1
16. 18729 CHAIN JR SHORT 59 PITCH* 1 64. 18336 CHAIN JR/DJ 151 PITCH 1
17. 12175 NUT 5/16-18 FLANGED 8 65. 16961 HUB CB SNAP RING SHIMANO* 1
18. 12218 SCREW 3/8-16x3/4 CARRIAGE 1 66. 16960 HUB CB DUST RING SHIMANO 1
19. 12178 NUT 3/8-16 FLANGED 3 67. 11939 SPROCKET 21T CB SHIMANO* 1
20. 19153 NUT AXLE SHIMANO* 2 68. 11667 HUB CB TRIKE SHIMANO* 1
21. 11961 TIRE 24x1.74 BSW 2 69. 17160 GRIP DEPTH CNTRL 3/8x2.25 1
22. 11976 TUBE 24x1.75 2 70. 12199 SCREW 14x3/4 TYPE A HEX HD 4
23. 11985 RIM STRIP 24x1.75 2 71. 18221 LEVER SEAT JR/DJ 1
24. 12012 WHEEL 24x1.75x36x.080 R. REAR 1 72. 17348 SPRING JR/JUNR/DJ/LATCH KEY 1
25. 18239 WHEEL 24x1.75 MAG R. REAR 1 73. 18089 SCREW 1/4-20x7/8 FLANGE HEAD 1
26. 11679 CONNECTING LINK 1 74. 11061 NUT NYLON 14-20 NYLON INSERT 1
27. 18201 CHAINGUARD JR 1 75. 18216 BASE SEAT JOY RIDER 1
28. 12172 NUT 1/4-20 FLANGED 9 76. 11121 SCREW 1/4-20x5/8 HHCS 4
29. 12232 WASHER 1/4 SAE 3 77. 18206 SEAT JOY RIDER 1
30. 11642 BEARING AXLE 5/8 ASF 107E 2 78. 11639 BASKET 1
31. 11120 SCREW 1/4-20x3/4 FLANGE HEAD 1 79. 18757 CHAIN JR LONG 113 PITCH* 1
32. 11952 SPROCKET 22T SOLID W/ ADAPTER* 1 80. 18983 DUST RING S/A* 1
33. 12241 SET COLLAR 5/8 5 81. 18913 HUB 3SPCB TRIKE W/ 22 SPKT* 1
34. 19238 FREEWHEEL 22T & ADAPTER JR 1 82. 12193 SCREW 10-32x1 PHIL PAN HD HD MS 1
35. 19211 PEDAL ASSY. JR/JUNR/DJ 2 83. 18049 NUT AXLE STURMY ARCHER* 1
36. 13994 FENDER 20" CHR JR/JUNR/DJ 1 84. 18986 WASHER ANTITURN S/A* 1
37. 12236 WASHER 5/16 SAE 3 85. 18993 INDICATOR PROTECTOR S/A* 2
38. 19002 NUT 3/8-24 FLANGED 2 86. 18997 INDICATOR CHAIN 3SPD. S/A* 1
39. 12301 WASHER 3/8 FLAT SAE 8 87. 18985 NUT AXLE RIGHT S/A* 1
40. 11078 WHL 12.5x2.25 W/TIRE/TUBE/BB 1 88. 18984 WASHER SPROCKET SPACER S/A* 1
41. 19154 BAND BRAKE ARM NUT 1 89. 18998 ADJUSTING BARREL S/A* 1
42. 19156 BAND BRAKE ARM STRAP 1 90. 18982 SNAP RING S/A* 1
43. 19155 BAND BRAKE ARM SCREW 1 91. 18746 HUBHOLDER 3SPCD GUIDE* 1
44. 11274 SCREW 1/4-20x5/8 CARRIAGE 1 92. 18995 CABLE 3SPD. S/A* 1
45. 18197 SCREW 5/16-18x5 CARRIAGE 1 93. 12285 HUB 3SPCB PLASTIC STOPPER* 1
46. 18337 FORK JR/DJ 1 94. 12239 SPACER 1/2 CB/3SPCB* 1
47. 17851 ADJ. BARREL & NUT BB 95. 19103 WASHER 3/8 EXT. TOOTH* 2
48. 18210 HANDLEBAR JOYRIDER 1
• OPTIONAL PARTS
TOOLS REQUIRED
3/8" WRENCH PLIERS
DRIFT PUNCH
1/2" WRENCH
5/32"ALLEN WRENCH
HAMMER
9/16" WRENCH COMMON
SCREWDRIVER
ADJUSTABLE WRENCH
PHILIPS SCREWDIVER
