4. Pedals
Install the pedals into the crank using a 9/16” open-end
wrench to tighten. Note: left hand and right hand thread.
5. Chain
Install the rear drive sprocket on the left rear axle. Install the
rear drive chain and join together with the connecting link.
Install the connecting link and spring clip using pliers. Slide
the frame sections apart evenly until the chain is tight
(approximately ¼” total up and down movement is
permissible) and securely tighten all the rear frame bolts and
the upper Allen screw in the center. Rotate the pedal several
times to check that the chain is running freely.
Keep fingers clear! If binding move rear sprocket to correct.
4
