Trak Machine Tools ProtoTRAK SMX K2

Questions and Answers

J
james85Aug 20, 2025
What to do if Trak Machine Tools ProtoTRAK SMX K2 parts have incorrect dimensions?
- B
  brewertimothyAug 20, 2025
  If your Trak Machine Tools Power Tool is producing parts with incorrect dimensions, consider the following: * Review the program for errors like transposed numbers or incorrect tool diameters. Ensure you're using ABS SET instead of INC SET when appropriate. * Verify that the configuration file (Code 313) does not show default values. If it does, load a saved configuration file from the floppy disk in the electrics cabinet using Code 141. * Recalibrate the machine, reset the backlash, and check repeatability and positional accuracy. * Consult Machine Tool & Setup Section 4.1.
S
Stephen GonzalezAug 26, 2025
What to do if axis runs away on Trak Machine Tools Power Tool?
- Q
  qgrahamAug 26, 2025
  If an axis on your Trak Machine Tools Power Tool is running away, consider these potential causes and solutions: * Reverse directions with codes 321 and 322 if sensors or glass scales are counting in the opposite direction of the motor encoder. * Refer to TRAK Sensors or Glass Scales diagnostic Section 4.6 or 4.7 if the sensor or glass scale is not reading. * See Motor diagnostics Section 4.4 to check for a bad motor encoder.
M
Matthew CooperAug 28, 2025
Why is there a taper cut on straight line move on Trak Machine Tools Power Tool?
- D
  daisysilvaAug 28, 2025
  If you observe a taper cut on a programmed straight line move with your Trak Machine Tools Power Tool, the following could be the cause: * Check the adjustment of the X and Y gibs. * Check for any looseness in the setup (tool, tool holder, part, vise, or fixture). * Check repeatability using the Repeatability and Positional Accuracy procedure. Step by step, carefully inspect the drive train for any looseness.
Z
Zachary CarterAug 31, 2025
What to do if axis will not jog on Trak Machine Tools Power Tool?
- W
  William JonesAug 31, 2025
  If an axis on your Trak Machine Tools Power Tool will not jog, consider the following: * Check the E-Stop, especially if both axes will not jog. * Shut down the system and wait 10 seconds before rebooting. * If only one axis will not jog, it could indicate a servo drive failure.
J
Justin FreemanSep 2, 2025
Why is axis motor motion not smooth on Trak Machine Tools Power Tool?
- J
  James GreenSep 2, 2025
  If your Trak Machine Tools Power Tool's axis motor motion is not smooth, consider the following: * Check the adjustment of the X and Y Gibs. * Make sure that the sensor or glass scale is installed correctly. * Recalibrate the machine. Reset the Backlash. Check Repeatability and Positional Accuracy.
M
Michael RodriguezSep 5, 2025
Why does Trak Machine Tools ProtoTRAK SMX K2 Power Tool axis slow down?
- A
  Allison LopezSep 5, 2025
  If your Trak Machine Tools Power Tool axis is slowing down, check the following: * Make sure the Table and Saddle Locks are unlocked. * Make sure all the Way surfaces are getting proper lubrication. * Check the adjustment of the X and Y Gibs. * The factory default for the maximum allowable Arc Accuracy is set at 0.001".
R
Ruben DavisSep 8, 2025
What to do if Trak Machine Tools ProtoTRAK SMX K2 display blanks?
- K
  Kimberly ThomasSep 8, 2025
  If the display on your Trak Machine Tools Power Tool blanks out, try the following: * Press any key to turn the screen back on if the screen saver has been activated. * Turn the power switch off, check the computer/ pendant fuses and cable connections if the system has shut down. * Double-check the connection from the computer module to the LCD. * Remove fuse and check continuity if fuse blown in pendant.
J
Jacqueline VegaSep 12, 2025
How to unlock keyboard on Trak Machine Tools ProtoTRAK SMX K2?
- C
  Cassandra CurrySep 12, 2025
  If your Trak Machine Tools Power Tool experiences keyboard lockup, here are a few things to try: * Shut down the system and wait 10 seconds to reboot the system, as a voltage drop/spike may have occurred. * Remove the RSG. Turn the system off and then on again. If the problem goes away and then re-appears when the RSG is plugged-in, replace the RSG.
C
Charlene BryantSep 13, 2025
What causes limited switch error on Trak Machine Tools Power Tool?
- D
  Deborah ColeSep 14, 2025
  If you're encountering a limited switch error on your Trak Machine Tools Power Tool (optional feature), consider these steps: * Remove and reseat jumpers if limit switch jumpers in cable breakout box are making poor contact. * Reset the Limit Switches using the procedures described above if Limit Switches are triggered. * Check for any pins that are loose, pushed in, or bent to fix poor Limit Switch Cable connection. * Try this Switch 2 limit switch cables on the cable breakout box if Limit Switch failure.
L
Lisa HawkinsNov 16, 2025
How to fix poor finish on Trak Machine Tools Power Tool?
- R
  Rebecca RamosNov 16, 2025
  If your Trak Machine Tools Power Tool is producing a poor finish, several factors could be responsible: * Ensure that the table and saddle locks are unlocked, as gib locks should never be used with a CNC machine. * Verify that the X and Y gibs are properly adjusted. * Confirm that the backlash values are not higher than what physically exists in the system, and that nothing is mechanically loose. * Inspect the drive train for any looseness, using the Repeatability and Positional Accuracy procedure. * Visually check all way surfaces for any pocks, scars, or excessive wear. Adjust the gibs if necessary. * Ensure adequate lubrication to ballscrews and way surfaces, checking the lube pump and oil lines. * Check for any looseness in the setup, including the tool, tool holder, par...
