RTAG nameplates: unit nameplate, compressor name-
plate, evaporator nameplate and oil separator name-
plate.
RTAG nameplate stick on the outer surface of the control
panel, compressor nameplate stick on the compressor
housing, evaporator nameplate stick on the heat ex-
changer shell, where its insulation has been open to look
at it, oil separator nameplate stick on oil separator shell.
Unit nameplate include following information, as Figure
1 Unit Nameplate:
Model number
Serial number
Nominal tonnage
Compressor quantity
Fan quantity
Rated Voltage / frequency / phase
Rated power
Refrigerant charge and type
Oil charge and type
Unit weight
Unit dimension
Compressor model number.
Compressor serial number.
Compressor electrical characteristics.
12 RTAG-SVX001H-EN
Utilization range.
Recommended refrigerant.
Overview
