1. Date Containing: Temperature of Inlet/outlet: 54/44ºF, Ambient Temperature: 95ºF, Scaling factor: 0.001 ft² ºF h/Btu.
2. Minimum start-up / operating ambient based on a 5 mph wind across the condenser.
3. Detail components structure / location please see Dimension sector.
4. Electric type could selected according unit voltage, but the current value in table is base on 400V/60HZ/3Ph.
16 RTAG-SVX001H-EN
Model
Refrigerant
Compressor
Model
Type
Starter
Circuits
Min load
Must hold current(1A/1B)
Must hold current(2A/2B)
Evaporator
Type
Rating flow
Rating WPD
Min flow
Max flow
Water storage
tube size
Air side heat exchanger
Fan type
Quantity
Power
Fan speed
Single fan Airflow
Fan current
Unit Max RLA(Max Compr+Fan+Control)
Control panel 1
Control panel 2
Unit start up amps
Control panel 1
Control panel 2
Refrigerant charge
ckt 1
ckt 2
Oil charge (the oil type show on unit nameplate)
ckt 1
ckt 2
Dimension
Length
Width
Height
Shipping weight
Operation weight
RTAG
R134a
%
A
A
gpm
psid
gpm
gpm
lb
inch
kW/per
RPM
CFM
A
A
A
A
A
Lb
Lb
gal
gal
inch
inch
inch
lb
lb
400
R134a
CHHW
(N5+N5, N5+N5)
YDEL
2
7,50%
231/231
231/231
Shell & Tube (CHIL)
1154
5,6
577
1730
369
8"
Axial flow
18
2
860
11478
4,7
504
504
676
676
326,3
326,3
4,2
4,2
88,4
97,6
20640
21008
500
R134a
CHHW
(N6E+N6E;N6E+N6E)
YDEL
2
7,50%
302/302
302/302
Shell & Tube (CHIL)
944
5,6
472
1416
455
8"
Axial flow
20
2
860
11478
4,7
651
651
752
752
406,0
406,0
4,2
4,2
88,4
97,6
22481
22935
Horizontal semienclosed screw compressor
Note:
Table 4. General data — 400 - 500 Ton 400 Volt -60Hz high efficiency (fixed speed fan)
467,5
456
To Next Page
