Trane A4AC3030A1000A - Troubleshooting Compressor Not Running

26 88-A4AC3001-1C-EN
Check for open IOL
(Internal Overload)
Check resistance of
C to S and C to R
Does the
resistance check
show an open
circuit from C to S
or C to R?
YES
Allow compressor
time to cool and
re-test
NO
Check for open
windings.
YES
Does a resistance check
show an open circuit
between R and S?
Replace the
compressor
NO
Check for locked
rotor
Is voltage present
at C to S and C
to R with locked
rotor amps on C?
YES
Check Start-
Capacitor and
Relay (if present)
and Run Capacitor
Do the start
components and
run capacitor
check good?
YES
Replace the
compressor
NO
Replace start
components and/
or run capacitor
NO
Check wiring to
compressor
C, S and R
Check for high
voltage to contactor
Is high voltage present
at T1 and T2 ?
YES
NO
Check power
supply from
disconnect and/or
breaker panel.
Compressor won’t run
Contactor is closed
TROUBLESHOOTING
