Table 2. Tube bundle locations for cooling only and free cooling units (mm)
Shell Cooling Only and Free Cooling Units
Size A B C D E F G H
32 629 67 283 184 813 457 254 670
50 781 73 238 244 943 588 365 705
80 1044 108 159 289 1111 715 489 1095
142 1178 108 168 677 1279 993 632 1127
210 1346 114 181 432 1498 1105 715 1162
250 1543 140 181 489 1743 1187 715 1225
Table 3. Tube locations for heat recovery and auxiliary condenser units (mm)
Shell Heat Recovery Auxiliary Condenser
Size J K L M J K L M
32 1381 260 470 1219 1390 232 356 1212
CVHE 50 1584 365 568 1371 1546 232 356 1429
CVHEF/G 50 1893 365 568 1473 1852 232 356 1540
80 2213 489 734 1432 2096 232 356 1749
142 2625 632 978 1880 2372 232 356 2226
210 2629 715 1108 1997 2632 232 356 1162
250 Not Available
Table 4. Typical shipping and operating weights (k) (see note 1)
Cond Size Aux Cond Size 80 Aux Cond Size 130 Heat Rec Cond Free Cooling
CDSZ Ship Oper Ship Oper Ship Oper Ship Oper
032S 374 479 435 566 961 1190 227 356
032L 374 479 435 566 1208 1480 227 356
050S 374 479 435 566 1438 1823 340 585
050L 374 479 435 566 1808 2262 340 585
080S 374 479 435 566 2422 2991 340 617
080L 374 479 435 566 3031 3710 340 617
142L 374 479 435 566 5525 6652 635 1089
210L 374 479 435 566 7268 8754 635 1089
Notes:
1. Unit-Mounted Starter Option = 236 Kg (Shipping and Operating)
2. Weights shown are accurate within ± 3% and are calculated with non-marine 1034 kPa water boxes. Marine-style water boxes may add considerably more weight;
contact LBU Marketing for details.
3. Operating weights include refrigerant, oil and water charges.
4. For more specific data on weights and isolator loading, refer to the unit submittal package.
