Unit Piping
22 CG-SVX038A-EN
Figure 4. Condenser piping schematic
Vibration Eliminator
Vibration Eliminator
Optional
Water
Regulating
Valve
UNIT
FACTORY
INSTALLED
OPTIONS
(IF ORDERED)
T
T
P
Condenser Out
Condenser In
Bypass Valve
Isolation Valve
Isolation Valve
Pressure Gauge
Temperature Gauge
Temperature Gauge
Valve for Pressure Measurement
Valve for Pressure Measurement
CUSTOMER PIPING
