Trane EDHUM070H - Specifications; Performance; Electrical; Features

4
Installation & Operation Instructions
SPECIFICATIONS
Width: 12" 12" 15 5/8"
Height: 12" 12" 16"
Length: 28" 22" 31 5/8"
Weight: 55 lbs. 54 lbs. 65 lbs.
WITH COLLARS
W/ OUT COLLARS
25
22"
12"
8"
12"
12"
12"
8"
12"
12"
Top Supply Option
15"
12"
28"
22"
THE COMPACT EDHUM070H
IS DESIGNED TO FIT IN TIGHT,
LOW-CLEARANCE SPACES
WHERE MOST DEHUMIDIFIERS
CANNOT. IDEAL FOR SMALL
HOMES, CONDO OR APARTMENT
APPLICATIONS, THIS DEHUMIDIFIER
IS ENERGY STAR RATED.
Front Side Back
PERFORMANCE
Water Removal 70 Pints / 8.75 Gallons
Efciency 5.0Pints/kWh
EnergyFactor 2.4L/kWh
Blower 150 CFM @ 0.0” WG
 140CFM@0.2”WG
 130CFM@0.4”WG
OperatingTemperature 49°FMin.,95°FMax.
Sizing Upto1,800Sq.Ft./18,000Cu.Ft.
ELECTRICAL
Power 580watts@80°Fand60%RH
SupplyVoltage 115volt–1phase–60Hz
Current Draw 5.1 amps
PowerCord 9’,115VAC,Ground
CircuitRequirement 15Amps
SPECIFICATIONS
DuctConnections 8”RoundInlet,8”RoundOutlet
DrainConnection 3/4”ThreadedFemaleNPT
Refrigerant R410A,15oz.
UnitDimensions 12”Wx12”Hx28”D
UnitWeight 55lbs.
SHIPPING
ShippingDimensions 15”Wx16”Hx31”D
ShippingWeight 65lbs.
PalletQuantity 12perpallet
UPCNumber 859029004632
ShippingOptions UPSandLT L
FEATURES
+ Small footprint (12” x 12” x 22”) ts low
prole spaces
+ Rotatable exhaust outlet provides for
horizontal or vertical discharge
+ Ducting option for fresh outdoor air
ventilation
+ Onboard dehumidistat with optional
DEH 3000/R digital control
+ Features MERV-13 lter for superior
air ltration
+ Push button reset for transformer
protection
MODEL EDHUM070H
PlugTypeB
(USA,MEX,CAN,JPN)
Specications are subject to change without notice. Performance is based on pints / gallons per day @80°F/60%RH.
Sizing is based on 10 foot ceiling height. Unit dimensions and weight are with collars on.
EDHUM070H
