23
Performance
Data
Q Fan and
Super Q II
Size 16
Standard fans can be selected ONLY in the shaded area.
Thrust restrains are to be used with fans Class 3 or motors 40 hp and up.
Minimum and Maximum Motor HP Ranges
Q Fan Size 16” Super Q Fan Size 16”
Min - Max Min - Max Min - Max Min - Max Min - Max
Motor HP Motor HP Motor HP Motor HP Motor HP
Class 1 Class 2 Class 3 Class 1 Class 2
Arrangement 9 1 - 2 1.5 - 5 5 - 15 1 - 2 1.5 - 5
Arrangement 1 ——5 - 15 NA NA
____
Fan RPM Line
- - - Motor HP Line
To Next Page
