50
Dimensional
Data and
Weights
Roughing-In Dimensions
Arrangement 9
Arrangement 9 Dimensions
Drive Unit
H Shaft Net Wt.
Size A L W Max. Dia. Lbs.
49 Class I 52
3
/8 76 57
1
/8 79
7
/8 1
11
/16 1020
49 Class II 52
3
/8 76 57
1
/8 85
1
/2 2
3
/16 1075
54 Class I 58 81
7
/8 62
3
/4 85
1
/2 1
15
/16 1090
54 Class II 58 81
7
/8 62
3
/4 91
1
/4 2
7
/16 1140
60 Class I 64
1
/8 92 69
3
/4 96
1
/4 2
3
/16 1730
60 Class II 64
1
/8 92 69
3
/4 108
1
/4 2
11
/16 1830
Approximate weights are without motor and drive.
