Trane FD17DCLFR000D Series User Manual

EAC-SF-13 Numbers in [brackets] are for 50 Hz international systems. 5
Service Facts
▲
WARNING
!
HAZARDOUS VOLTAGE! DISCONNECT ALL ELECTRIC
POWER, INCLUDING REMOTE DISCONNECTS BEFORE
SERVICING. FOLLOW PROPER LOCKOUT/TAGOUT
PROCEDURES TO ENSURE THE POWER CAN NOT BE
INADVERTENTLY ENERGIZED. FAILURE TO
DISCONNECT POWER BEFORE SERVICING COULD
RESULT IN DEATH OR SERIOUS INJURY.
ELECTRICAL CONNECTIONS TO A STANDARD 24 VOLT AIR HANDLER
GAM5 / A/TAM4
A/TAM7
Field wiring
O
R
B
YI
W1
YO
Y2
BK
G
W2
W3
(In)
(Out)
O
R
B
YI
W1
YO
G
W2
W3
For use with Whole House
Air Cleaner
RED
BLUE
GREEN
BLACK
GRD
Air Cleaner
Plug
BROWN /
Future Use
Power / Control
Wiring Cable and Plug
Unused
WHITE
For use with Whole House
Air Cleaner
RED
BLUE
GREEN
BLACK
GRD
Air Cleaner
Plug
BROWN /
Future Use
Power / Control
Wiring Cable and Plug
Unused
WHITE
