Trane M4MHW17-A - Installation Overview and Components; Component Identification

(Sold Separately)
* Field provided
1
(8)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(10)
(9)
1 - Front Panel
2 - Filter
3 - Guide Louver
4 - Wall Pipe*
5 - Bind Tape*
6 - Connection Wire*
7 - Drainage Pipe*
8 - Power Cable*
9 - Wired Controller
(Sold Separately)
10 - Remote Controller
Indoor Unit
Outdoor Unit
Typical Installation Setup
8 88-M4MHW17-1B-EN
Installer's Guide
