Trane Purifier Plus Purge - Field Supplied Items

6 PRG-IOM-3E
General Information
Field supplied items
• (3) 3/8” Flare nuts
• 3/8” OD refrigeration-grade copper tubing (Length determined by
location of canister)
• (4) ¼” Bolts (Use when canister is bolted directly to chiller such as
Option #3 in Figure 2).
Figure 1 — Purifier Plus™ Canister and Bracket
Outlet
Holder Bracket
Inlet
Canister
Mounting
Bracket
