Trane Purifier Plus Purge - Purifier Purge Pump Out Minutes; Change Canister Label and Unit Nameplate

8 PRG-IOM-3E
Installation
Table 1: Purifier Purge™ Pump Out Minutes
Model
Chiller Refrigerant
R113 R11 R123
PRGA 5000 1500 2000
PRGB 5000 3000 4000
PRGC 5000 3000 4000
Figure 4 — Change Canister Label
Change Purifier Plus™ Canister
AT A Minutes
OR B Date
A = Purge pump out timer value at installation
plus appropriate value from Table 1.
B = Installation date plus 3 years.
Figure 5 — Typical Unit Nameplate
Order No. Example
Model No. PRPA000N2A0
Serial No. L93C02684
For use with Refrigerant HCFC-123
Only
Purifier Purge
Meter Date
Installed _________ ________
Removed _________ ________
Sales Order No. ______________
Purge Model _________________
Chiller Manufacturer ___________
Chiller Model _________________
URC X39000746-01
