Trane R-22 User Manual

Electrical Characteristics
Remark:
MCA: Max. Current Amps. (A)
MFA: Max. Fuse Amps. (A)
W: Fan Motor Rated Output (W)
FLA: Full Load Amps. (A)
OFM:Outdoor Fan Motor
60Hz Models
Indoor Outdoor Hz Voltage Min. Max. MCA MFA W FLA
2MWW0509G1 2TWK0509G1 60Hz 220V 198V 242V 5.6 15 30 0.37
2MWW0512G1 2TWK0512G1 60Hz 220V 198V 242V 7.1 15 30 0.35
2MWW0512G9 2TWK0512G9 60Hz 115V 103V 127V 13.6 25 30 0.7
2MWW0518G1 2TWK0189G1 60Hz 220V 198V 242V 10.9 25 60 0.56
2MWW0524G1 2TWK0524G1 60Hz 220V 198V 242V 14.0 25 60 0.59
2MWW0530G1 2TWK0530G1 60Hz 220V 198V 242V 17.8 25 90 1.42
2MCW0509G1 2TTK0509G1 60Hz 220V 198V 242V 5.6 15 30 0.37
2MCW0512G1 2TTK0512G1 60Hz 220V 198V 242V 7.1 15 30 0.35
2MCW0512G9 2TTK0512G9 60Hz 115V 103V 127V 13.6 25 30 0.64
2MCW0518G1 2TTK0189G1 60Hz 220V 198V 242V 10.9 25 60 0.56
2MCW0524G1 2TTK0524G1 60Hz 220V 198V 242V 14.0 25 60 0.59
2MCW0530G1 2TTK0530G1 60Hz 220V 198V 242V 17.8 25 90 1.42
50Hz Models
Indoor Outdoor Hz Voltage Min. Max. MCA MFA W FLA
2MWW0509GB 2TWK0509GB 50Hz 220V 198V 242V 6.3 15 30 0.37
2MWW0512AB 2TWK0512AB 50Hz 220V 198V 242V 7.8 15 30 0.42
2MWW0518AB 2TWK0518AB 50Hz 220V 198V 242V 10.8 25 48 0.62
2MWW0524AB 2TWK0524AB 50Hz 220V 198V 242V 13.1 25 60 0.58
2MWW0530AB 2TWK0530AB 50Hz 220V 198V 242V 16.5 25 90 0.8
2MCW0509GB 2TTK0509GB 50Hz 220V 198V 242V 6.3 15 30 0.37
2MCW0512AB 2TTK0512AB 50Hz 220V 198V 242V 7.8 15 30 0.42
2MCW0518AB 2TTK0518AB 50Hz 220V 198V 242V 10.8 25 48 0.62
2MCW0524AB 2TTK0524AB 50Hz 220V 198V 242V 13.1 25 60 0.58
2MCW0530AB 2TTK0530AB 50Hz 220V 198V 242V 16.5 25 90 0.8
Model Power Supply Current OMF
Model Power Supply Current OMF
23
