7. Remove electronic expannsion valve
Unsolder the weld spots of eletronic expansion
valve connecting with other pipelines to remove it.
8. Remove gas valve and liquid valve
Unscrew the 2 screws fixing the gas valve and
unsolder the weld spots of gas valve and suction
pipe to remove the gas valve.
Unscrew the 2 screws fixing the liquid valve and
unsolder the weld spots of liquid valve and suc-
tion pipe to remove the liquid valve.
screws
gas valve
electronic expannsion valve
liquid valve
9 . Remove compressor
Unsolder the 2 weld spots of the compressor and
unscrew the 3 feet nuts and remove the was-
heres fixing the compressor to remove it.
compressor foot
58
