400X CompactFlash Card
Transcend Information Inc.
V1.0
8

Input Leakage Current
Note: In Table 1 below, x refers to the characteristics described in table 2. For example, I1U indicates a pull-up resistor with a type 1
input characteristic.
Table 1: Input Leakage Current
Type Parameter Symbol
Conditions MIN
TYP
MAX
Units
IxZ Input Leakage Current
IL Vih = Vcc / Vil = Gnd
-1
1 µA
IxU Pull-Up Resistor RPU1 Vcc = 5.0V 50k
500k
Ohm
IxD Pull-Down Resistor RPD1 Vcc = 5.0V 50k
500k
Ohm
Note: The minimum pull-up resistor resistance meets the PCMCIA PC Card specification of 10k ohms but is intentionally higher in the
CompactFlash Specification to reduce power use.

Input Characteristics
Table 2: Input Characteristics
MIN
TYP MAX
MIN
TYP MAX
Type
Parameter Symbol
VCC = 3.3 V VCC = 5.0 V
Units
1
Input Voltage
CMOS
Vih
Vil
2.4 0.6 4.0
1
0.8
Volts
2
Input Voltage
CMOS
Vih
Vil
1.5 0.6 2.0 0.8
Volts
3
Input Voltage
CMOS Schmitt
Trigger
Vth
Vtl
1.8
1.0
2.8
2.0
Volts
Notes: 1) The host provides a logic output high voltage for a CMOS load of .9 x VCC. For a 5 volt product, this translates to .9 x
4.5 = 4.05 volts minimum Voh.

Output Drive Type
Note: In Table 3 below, x refers to the characteristics described in Table 4. For example, OT3 refers to Totem pole output with a type
3 output drive characteristic.
Table 3: Output Drive Type
Type Output Type Valid Conditions
OTx Totempole Ioh & Iol
OZx Tri-State N-P Channel Ioh & Iol
OPx P-Channel Only Ioh Only
ONx N-Channel Only Iol Only
