IPoster diagram
Note:
① Display area
② Main frame
③ Hanging accessories installation area
④ LOGO area
⑤ Nitrogen spring
⑥ Stuck
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
⑬
⑭
⑮
⑯
⑦ Port area from top: LAN 1, LAN2, HDMI IN, HDMI OUT, AUDIO, LAN, USB1, USB 2, USB 3
⑧ Supporter groove
⑨ Power
⑩ WIFI antenna
⑪ HDMI port
⑫ Cascade port
⑬ Pedestal mounting screw hole
⑭ USB port
⑮ Power indicator,
signal indicator
⑯ Input station
