Configuration of a shelf in presentation layout:
To install bottles on a presentation shelf:
Insert the shelf at the desired position.
Place a wooden locking pin in each of the 2 holes located on the right and
left side of the upper face approximately 15 cm from the front of the shelf
(see diagram): these pins secure the shelf to the thermoformed wall and
prevent any inappropriate movement.
- Start by placing the bottles in each recess on the back row, with the base
of the bottle towards the back. (6 traditional Bordeaux type bottles).
- Continue stacking the bottles on the back row (7 + 6 + 7 + 6 = 26 traditional
Bordeaux type bottles), ensuring that none of the bottles touches the back
wall.
- To present your bottles, place them in a vertical position on the front of
the shelf (maximum capacity: 6 traditional Bordeaux type bottles).
When in presentation layout, the shelf has a maximum capacity of 32 (26+6)
traditional Bordeaux type bottles.
- Start by placing the bottles in each recess on the back row, with the base
of the bottle towards the back.
- Continue with the front row, placing the bottles in the opposite direction.
- Continue stacking the bottles, ensuring that none of the bottles touches
the back wall.
A storage shelf can hold a maximum of 6 rows of 13 bottles, or 78 traditional
Bordeaux type bottles (100 kg).
Shelf in sliding version configuration:
To place bottles on a sliding shelf, carry out the following:
- Install the shelf in the selected location.
- Place a wooden locking pin in each of the two holes located on the
right and left of the upper face approximately 4cm to the rear of
the shelf
(see diagram)
: when the shelf is slid forwards, these pins
stop it from sliding completely out of the cabinet.
- Start by placing the bottles in the rear recesses with the base of the
bottles towards the back.
- Continue by placing the bottles in the front recesses facing them in
the opposite direction.
