Indoor Mobility Point™ Quick Start Guide
6
Trapeze Networks
MP-422/432/522 Package Contents
The shipping carton for an MP contains the following items:
1. One MP
2. Mounting kit including:
❑ One mounting bracket (attached to the MP)
The MP-522 package contains a specific mounting bracket (attached to the MP)
❑ One paper mounting template (used for marking cutting areas and screw holes)
The MP-522 package contains a specific mounting template with different dimensions than the
template used for the MP-422 and MP-432.
❑ One two-piece 14.2-millimeter (9/16-inch) T-bar clamp
❑ One two-piece 15.9-millimeter (5/8-inch) T-bar clamp
❑ One two-piece 23.9-millimeter (15/16-inch) T-bar clamp
❑ Two #6 sheet metal screws and two drywall anchors
3. One documentation pack that includes quick mounting instructions and a user guide.
Figure 1–1. Shipping Carton Contents
T-bar clamps
Mounting template
Mounting hardware
Mobility Point
840-9502-0001
MP-522 mounting
bracket (included
with MP-522 and
MP-522E orders)
MP-422 and MP-432
mounting bracket
MP-522 mounting
template
