Main Components
3
2
10
13
9
11
6
12
5
4
87
14
15
1
1. Side feed funnel
2. Upper feed funnel
3. Upper outlet
4. Lower outlet
5. Closing cover
6. Corner
7. Square rods
8. Tilting plate
9. Motor
10. Battery (for model 16 HP)
11. Cable for maneuvers
12. Belt tensioner
13. Lever for feeding the upper funnel
14. Belt protection
15. Tires
