Model TRF 80G
1233
655
645
4
11
9
5
10
6
7
8
2
3
1
655
1233
645
Image merely illustrative.
1. Grain funnel
2. Green crop feeder
3. Cover
4. Lower downward exit
5. Counter cutting blade
6. Grain input adjuster
7. Body
8. Green crop feeder cover
9. Rubber pad
10. Gasoline-powered engine
11. Upper material outlet (only for green crop)
Models TRF 90 and TRF 90F / TRF 300 and TRF 300F
7
Grounding
point
Image merely illustrative.
10
7
6
13
9
12
11
1
4
3
2
8
5
66
61
45
120
29
1. Belt protection guard
2. Grain funnel
3. Green crop feeder
4. Cover
5. Lower downward exit
6. Counter cutting blade
7. Grain input adjuster
8. Body
9. On/off switch
10. Green crop feeder cover
11. Rubber pad
12. Electric motor
13. Upper material outlet (only for green crop)
