Traynor DynaGain DG65R - Rear Panel Features and Specifications; Footswitch and Speaker Connections; DG65 D Specifications; DG65 R Specifications

4
The ¼-inch T.R.S. Preamp Out jack can also be
used as a direct line out. The -10dBu output is ideal
for most guitar effects pedals and professional signal
processors. You can also use this output to slave the
DG65 with another guitar amplifier by plugging into the
Amp In jack of the slave amplifier.
The ¼-inch T.R.S. Amp In jack accepts an input
signal that is passed to the power amplifier, so it can
be used as a power amp in. And, since the Master
control section affects the Amp In signal, you can use
Contour and Reverb to further shape your tone.
Footswitch Jack (Channel Select/Boost)
23
When connected, the footswitch pedal is the
exclusive control for the Channel Select and Boost
functions, bypassing the switches on the DG65’s
control panel. It features dual-latching switches,
each with a separate LED indicator.
Footswitch-induced noise is never an issue. The
switching is accomplished with internal FET’s so there is
no audio flowing through the footswitch cable. The DG65 is
compatible with most aftermarket latching dual-footswitch
pedals although we do recommend the Traynor TFS-2B
latching dual-footswitch, with 10-foot cable (included).
Rev /EFX Defeat Jack (DG65D) or Reverb (DG65R)
22
Connecting a footswitch to the rear mounted Rev /
EFX defeat jack (Reverb on the DG65R) can defeat
the internal effects. The included footswitch can
be used for this purpose. Again, since switching is
accomplished using internal FET’s, no audio is flowing
through the footswitch cable and noise is not an issue.
External Speaker Jack and Internal Speaker
Defeat Switch
24
25
The chassis mounted ¼-inch jack allows convenient
connection of an 8-ohm external speaker cabinet. If you
disconnect the internal 12-inch Eminence Red Coat®
speaker by depressing the Internal Speaker Defeat
switch, you can connect up to two 8-ohm external
cabinets (minimum speaker load of 4-ohms).
S
p
ecifications
Type
Solid-State Guitar Amplifier
Cabinet Program Power (Watts)
65
Cabinet Impedance (ohms)
8
Power @ min. impedance (Watts)
65
Minimum Impedance (ohms)
4
Burst Power - 2 cycl
e
85-watts
Speaker Configuration - LF (Size / Power)
12 inch / 75 Watts
Input Channel
s
Hi / Lo
Channel 1 - inputs
1/4 inch phone
Channel 1 - controls
Gain, Volume, Treble, Bass, Middle
Channel 1 - switche
s
Boos
t
Channel 2 - inputs
Shares ch 1 inpu
t
Channel 2 - controls
Gain, Volume, Treble, Bass, Middle
Channel 2 - switche
s
Bright
Channel Switching
Yes / Footswitchabl
e
Master Volume Contro
l
Yes
Main Tone Controls
Contour
Input Sensitivity (mV
)
20
Master Output
s
Preamp Out / Headphone Ou
t
Line Out (type / configuration)
1/4 inch TRS / Rear (Effects Send)
Line Out Sensitivity (Vrms)
300m
V
Effects Volum
e
Reverb
Effects Loop / Locatio
n
Post Preamp / Rear
Effects Footswitch / Function
Yes / Channel Select, Boost
Effects Return Sensitivity (Vrms
)
300m
V
Internal Reverb / Effect
s
Accutronics Spring Reverb
LED Indicator
s
Channel Select, Boost, Powe
r
Protection
Short Circuit, Thermal
External speaker output / locatio
n
1/4-inch, Rear / Internal Speaker Defeat Switc
h
Headphone Jack
Yes / Front Panel / Dyna-Sound Speaker Emulatio
n
North American Made
3-Stage Dyanamic Tube Emulatio
n
Transconductance Power Amplifier for further tube
All Plywood Contruction
Perforated Steel Grill
e
Dimensions (DWH, inches
)
10 x 23.5 x 18
Dimensions (DWH, cm
)
25 x 60 x 46
Weight (lbs / kg
)
40 / 18
Other Features
S
p
ecifications
Type
Solid-State Guitar Amplifier
Cabinet Program Power (Watts)
65
Cabinet Impedance (ohms)
8
Power @ min. impedance (Watts)
65
Minimum Impedance (ohms)
4
Burst Power - 2 cycl
e
85-watts
Speaker Configuration - LF (Size / Power)
12 inch / 75 Watts
Input Channel
s
Hi / Lo
Channel 1 - inputs
1/4 inch phone
Channel 1 - controls
Gain, Volume, Treble, Bass, Middle
Channel 1 - switche
s
Boos
t
Channel 2 - inputs
Shares ch 1 inpu
t
Channel 2 - controls
Gain, Volume, Treble, Bass, Middle
Channel 2 - switche
s
Bright
Channel Switching
Yes / Footswitchabl
e
Master Volume Contro
l
Yes
Main Tone Controls
Contour
Input Sensitivity (mV
)
20
Master Output
s
Preamp Out / Headphone Ou
t
Line Out (type / configuration)
1/4 inch TRS / Rear (Effects Send
)
Line Out Sensitivity (Vrms)
300m
V
Effects Volum
e
Reverb / Effect
s
Effects Loop / Locatio
n
Post Preamp / Rear
Effects Footswitch / Function
Yes / Channel Select, Boost
Effects Return Sensitivity (Vrms
)
300m
V
Internal Reverb / Effect
s
16 Preset DSP, Seperate Digital Reverb
LED Indicator
s
Channel Select, Boost, Powe
r
Protection
Short Circuit, Thermal
External speaker output / locatio
n
1/4-inch, Rear / Internal Speaker Defeat Switc
h
Headphone Jack
Yes / Front Panel / Dyna-Sound Speaker Emulatio
n
North American Made
3-Stage Dyanamic Tube Emulation
Transconductance Power Amplifier for further tube
All Plywood Contruction
Perforated Steel Grill
e
Dimensions (DWH, inches
)
10 x 23.5 x 18
Dimensions (DWH, cm
)
25 x 60 x 46
Weight (lbs / kg
)
40 / 18
Other Features
DG65RDG65D
