2
Phones Jack
Connect standard stereo headphones to this jack
using a ¼-inch stereo plug.
Note: the internal speaker is disconnected when the
Phones jack is in use.
Power/Battery Status Light
When the power switch is on and the battery is
fully charged, this LED illuminates yellow. The LED
illuminates red when the battery needs recharging.
Power Switch
Use this switch to turn the amplifier on and off. Switch
it OFF when charging the battery.
Rear Panel
DC Charger Connector
Connect the 15 VDC charger to the amp here to
recharge the battery (power switch off), then plug the
charger into an AC outlet. When fully charged, the
battery should provide approx.10 hours of amplifier use.
NOTES:
1. The internal battery should be replaced by
authorized service technicians only!
2. For best performance, ensure that the TVM10 is
switched off while the DC charger is connected. The
TVM10’s battery charging system is not designed as
an AC power source. Operate on battery power only.
Charger LED
This LED illuminates when the amp is being
charged. Once the battery is fully charged, this LED
will dim and turn off. The battery requires 24-hours
to be recharged properly.
Specifications
Type
Combo
Speaker Configuration - (size / Power)
6-inch + tweeter / 15 Watts
Input Channels
2
Channel 1 - inputs
Combi (1/4-inch + XLR female)
Channel 2 - inputs
1/4-inch
Aux inputs
2x RCA
Master Controls
Bass, Low-Mid, Hi-Mid, Treble
LED Indicators
Power
Headphone Jack
Yes
Other Features
Rechargable battery (usage with full charge, 10-hours)
Input of charger: 120V 600mA
Output of charger: 15V 1500mA
Dimensions (DWH, inches)
10.25 x 13.75 x 11.75
Dimensions (DWH, cm)
260 x 345 x 300
Weight (lbs / kg)
25 / 11.32
