Traynor YGL2 - Page 11

BLOCK-DIAG-YGL2-00-2v0.ai
Block Diagram for YGL 2
DESIGNED & MANUFACTURED BY YORKVILLE SOUND
+
-
+
-
Mono
1/4-inch
Input Footswitch
Reverb Defeat Channel Select
Preamp
USA
V1:A
0 dB
Splitter
Send Rtn
Accutronics® Tank
4EB3C1B
V1:A
V1:A EQ
V3:A V4:A
Power
Amp
External
Speaker Out
YGL2
YS#7085
8-ohms
Grn Blk
Pre-Amp
Out
Amp In
TYPE: YS1095
Volume
Reverb
Master
Volume
Volume
Gain
EQ
V1:B
BRIT
O. D. Channel Clean Channel
Bright
V1:A
V2:A
EQ
V2:B V3
V1:B
USA
BRIT
DISCONNECT POWER WHEN
REPLACING TUBES
DÉBRANCHÉ L’APPAREIL AVANT
DE REMPLACER LES LAMPES
POWER
6BQ5
V8
POWER
6BQ5
V7
PREAMP
12AX7
V2
SPLITTER
12AX7
V4
POWER
6BQ5
V6
POWER
6BQ5
V5
12AX7
V1
